Technical parameters:

* voltage: 230V, power: 50HZ

* input power: 850W

* no-load speed: 750r/min

* rated times of impact: 2920/min

* drilling capacity: (concrete: diameter: 30MM

Steel: diameter: 16MM

Wood: diameter: 40MM)

Electronic structure (configured according to GS certificate requirements) :

* European double round insert, net line length: 1.8m

* power plug: jl-2 16A/250V VDE

* power conductor: VDE h07rn-f 2x1.0mm2 NINGB

* capacitor: tns-3th, *****, VDE,EN132400

* switch: fa2-6/2w7, 6(6)A250V, 10(10)A 125v-5e4, WUYUANANELECTRIC

Motor: 55mm, diameter 73mm, diameter 43mm

Bearings: 608ZZ,CXGS, iron cover

Commutator: KEZH

Each color: * chassis: > pa6-gf30 < red, RAL3000 red

* auxiliary handle: >PP< black

* soft skin at the mouth of the handle: black

* function handle: black

* drill and hammer drill handles: black

* use the switch button: black

*SDS set: red RAL3000

Standard configuration:

*SDS drill bit: 8X150MM, 10X150MM, 12X150MM

*SDS chisel (sharp and flat): 14X250MM

* one dust cover and one bottle of lubricating oil
