* factory article no. : p1u-td-1/2 ', products are produced according to GS and CE standards
Product up to FFU GOOD standard.
* technical parameters:
1. Rated power :950W
2. Rated voltage: 230v-50hz
3. Rated speed: 2300 RPM
4. Torque: 450 n. M
5. With 4 sleeves (17, 19, 21, 22mm)
* product color (specific to our company's packaging product color scheme standard, the following is only for reference)
1. Product body: RAL3000 red, see the color card of sample seal provided by our company for details
2. Black auxiliary handle. Screws should not rust
3. Black start switch
4. Black soft skin
5. Silver gray gear box with black soft glue.
6. Black sleeve, CHROME VANADIUM
7. Black blow box with metal clasp.
8. Black screw
* electronic components table of products (manufactured in full accordance with the requirements of GS certificate)
1. Plug: European two-circle plug, VDE standard, 16A/250V, jy-02
2. Wire: rubber wire, VDE, h07rn-f, 2x1.0mm2, jingyielectronics, exposed 2.5m
3. Capacitor: tns-3h, 0.33nf, 250v-m25/085/21c,VDE,
4. Switch: JIABEN, FD2 8/2 g - X, eight (8). A, 250 v, 5 e4. Take 1 square inductance TUV/GS standard
5. Motor: cold-rolled silicon steel sheet, enameled copper wire, stator diameter 72mm, length 41mm, rotor diameter 44MM, length 41mm
6. There are 2 round inductors beside the carbon brush
7. Case: pa6-gf30, new material
8. Bearing: NZJY608ZZ
9. Wind blade pa6-gf30, diameter 76mm, 12 pieces white
* random accessories:
1. Manual 1, must be in Arabic
2. One warranty card
3. One extra carbon brush
4. 4 sleeves
* provide 2 free rotors +2 free switches for guest maintenance.
Title | Item | Specs | Packing | Packing Number | WeightKG | Long | Wide | High |
---|---|---|---|---|---|---|---|---|
Electric wrench | YAE2335 | 450N.m | carton | 2 | 11.5 | 39 | 26.5 | 33 |
